12v Spoof Notes:

PbA Ranger EVs have 44 sense leads. 40 leads - numbers 0 to 39 - connect to the 39 8v modules, two leads for pack + and -, and two leads for low and high leak. Sense lead 0, - pack, and low leak leads all connect together at the Pack Negative and sense lead 39, + pack, and high leak leads all connect together at the Pack Positive. This diagram shows how sense leads 1 through 38 connect to the 26 12v modules and resistors.
